| Manufacturer | AUO |
| Model Name | G101STN01.C |
| Screen Size | 10.1 inch |
| Pixel Number | 1024(RGB)×600 , WSVGA |
| Active Area(mm) | 222.72 × 125.28 (H×V) |
| Outline(mm） | 235 × 143 × 5.2 (H×V×D) |
| Bezel Area(mm) | 226.43 × 128.1 |
| Treatment | AG , 3H |
| Luminance | 500 cd/m² (Typ.) |
| Contrast Ratio | 500 : 1 (Typ.) (TM) |
| Viewing Angle |
70/70/60/60 (CR≥10) Left/Right/UP/Down |
| Response | 20 (Typ.)(Tr+Td) ms |
| Work Mode | TN , Normally white , Transmissive |
| Color Depth | 262K/16.7M , 45% NTSC |
| Backlight | WLED , 50K hours , with LED Driver |
| Net Weight | 180g (Typ.) |
| Touchscreen | without |
| Signal Type/interface Type | LVDS (1 ch, 6/8-bit) , 40 pins |
| Voltage Supply | +3.3 V (Typ./Max.) |
| Max. Ratings |
Storage Temp.: -30 ~ +80 (°C) Operating Temp.: -30 ~ +80 (°C) |
| Package |
AUO Original package; 35 pcs/ carton; weight : 9.9Kgs; size : 528(L) x 348(W) x 252(H)mm |
