| Manufacturer | Innolux |
| Model Name | AT065TN14 |
| Screen Size | 6.5 inch |
| Pixel Number | 800(RGB)×480 , WVGA |
| Active Area(mm) | 143.400 x 76.704 (H×V) |
| Outline(mm） | 155.2 x 89.4 x 5.5 (H×V×D) |
| Dot pitch(mm) | 0.05975 x 0.1598 (W×H) |
| Treatment | Anti-Glare |
| Luminance | 400 cd/m² (Typ.) |
| Contrast Ratio | 500 : 1 (Typ.) (TM) |
| Viewing Angle | 70/70/50/70 (CR≥10) Left / Right/UP /Down |
| Response | 10/15 (Typ.)(Tr/Td) ms |
| Work Mode | TN, Normally white, Transmissive |
| Color Depth | 262K/16.7M , 50% NTSC |
| Backlight | WLED, 20K hours, without Driver |
| Net Weight | 127g |
| Touchscreen | without |
| Signal Type/interface Type | Parallel RGB (1 ch, 6/8-bit) , FPC , 50 pins |
| Voltage Supply | +3.3 V |
| Max. Ratings | Storage Temp. : -30 ~ +85 (°C) Operating Temp. : -30 ~ +85 (°C) |
| Package | Innolux original package; 50 pcs/ctn; weight : 9.085Kgs; size : 530(L) x 355(W) x 255(H)mm |
Innolux 6.5 inch tft lcd panel AT065TN14 with 800(RGB)x480 WVGA resolution, brightness 400 cd/m². This lcd display's working temperature is -30 ~ +85 (°C) and it's storage temperature is -30 ~ +85 (°C). Based on it's white LED backlight. This model is recommended for industrial use.
Matched resistive touch and capacitive touch available. Also we have matched HDMI driver board.
Original A Grade 6.5 inch 800x480 WVGA Innolux TFT LCD Panel RGB LCD Module AT065TN14 With 400nits, FPC 50pin, Touchscreen And Controller Board.
Hangzhou LEEHON Technology is one of the main agents of AUO/BOE / Kyocera/ Innolux TFT- LCD module in China
mainland, founded in 2009, the products vary from 2.5 to 43 inches, which include GD (Industrial grade), AV (car class),
PID (General Application) and other related products etc.,superior quality and competitive price, our products are sold
very well in North&South America, Western Europe and Southeast Asia.
We can supply total set of display solution:
TFT LCD screen + touch screen + controller board + cables + open frame.
