| Manufacturer | IVO |
| Model Name | M070AWPA R0 |
| Screen Size | 7 inch |
| Pixel Number | 800(RGB)×480 , WVGA |
| Active Area(mm) | 152.4 x 91.44 (H×V) |
| Outline(mm） | 166.6 x 105.8 x 7.8 (H×V×D) |
| Pixel Pitch(mm) | 0.1905 x 0.1905 mm (H×V) |
| Treatment | Anti-glare , 3H |
| Luminance | 1000 cd/m² (Typ.) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85(CR≥10) Left / Right/UP /Down |
| Response time | 20 (Typ.)(Tr/Td) ms |
| Display Mode | IPS , Normallyblack , Transmissive |
| Color Depth | 16.7M , 72% NTSC |
| Backlight | WLED , 30K hours , with LED Driver |
| Net Weight | 206g |
| Touchscreen | without |
| Signal Type/interface Type | Parallel RGB (1 ch, 8-bit) , FPC , 50 pins |
| Voltage Supply | +3.3 V |
| Max. Ratings |
Storage Temp.: -40 ~ +90 (°C) Operating Temp.: -30 ~ +85 (°C) |
| Package |
IVO Original package; 40 pcs/ctn |
