| Manufacturer | Kyocera |
| Model Name | TCG104SVLQAPNN-AN20 |
| Screen Size | 10.4 Inch |
| Pixel Number | 800(RGB)×600 , SVGA |
| Active Area(mm) | 211.2 × 158.4 (H×V) |
| Outline(mm） | 240.7 × 180.2 × 9 (H×V×D) |
| Pixel Pitch(mm) | 0.088 × 0.264 (H×V) |
| Treatment | Anti-Glare |
| Luminance | 400 cd/m² (Typ.) |
| Contrast Ratio | 500 : 1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (CR≥10) Left / Right/UP /Down |
| Response time | 18/12 (Typ.)(Tr/Td) ms |
| Display Mode | AWV , Normally black , Transmissive |
| Color Depth | 16.7M , 51% NTSC |
| Backlight | WLED , 70K hours , with LED Driver |
| Net Weight | 470g |
| Touchscreen | without |
| Signal Type/interface Type | LVDS (1 ch, 8-bit) , 30 pins |
| Voltage Supply | +3.3 V |
| Max. Ratings |
Storage Temp.: -30 ~ +80 (°C) Operating Temp.: -20 ~ +70 (°C) |
| Package | Kyocera Original package |
