| Manufacturer | TIANMA |
| Model Name | P0700WVN1MB01 |
| Screen Size | 7 inch |
| Pixel Number | 800(RGB)×480, WVGA |
| Active Area(mm) | 154.08 × 85.92 (H×V) |
| Outline(mm） | 164.9 × 100 × 5.7 (H×V×D) |
| Pixel Pitch(mm) |
0.1926 (H) x 0.179(V)
|
| Treatment |
Anti-Glare
|
| Luminance | 450 cd/m² (Typ.) |
| Contrast Ratio | 800 : 1 (Typ.) (TM) |
| Viewing Angle | 80/80/80/60 (Typ.) |
| Response | 15 (Typ.)(Tr/Td) ms |
| Work Mode | TN, Normally white, Transmissive |
| Color Depth | 16.7M , 50% NTSC |
| Backlight | WLED, 30K hours, without driver |
| Net Weight | 160g |
| Touchscreen | without |
| Signal Type/interface Type | TTL (1 ch, 8-bit) , FPC , 50 pins |
| Voltage Supply | 3.3V |
| Max. Ratings |
Storage Temp.: -30 ~ +80 (°C) Operating Temp.: -20 ~ +70 (°C) |
| Package |
TIANMA Original Package; 60 pcs/ctn; weight : 14.2 Kgs; size : 544(L)mm x 365(W)mm x 250(H)mm |
