| Manufacturer | TIANMA |
| Model Name | TM070RDHG25 |
| Screen Size | 7 inch |
| Pixel Number | 800(RGB)×480 , WVGA |
| Active Area(mm) | 154.08 x 85.92 (H×V) |
| Outline(mm） | 164.9 x 100.0 x 5.7 (H×V×D) |
|
Pixel pitch(mm)
|
0.1926 x 0.1926 (H×V) |
| Treatment |
Anti Glare
|
| Luminance | 450 cd/m² (Typ.) |
| Contrast Ratio10 | 00 : 1 (Typ.) (TM) |
| Viewing Angle | 80/80/60/80 (Typ.) |
| Response | 15 (Typ.)(Tr/Td) ms |
| Work Mode | TN, Normally white, Transmissive |
| Color Depth | 262K/ , 50% NTSC |
| Backlight | WLED, 20K hours, without driver |
| Net Weight | TBD |
| Touchscreen | without |
| Signal Type/interface Type | LVDS (1 ch, 6-bit) , 20 pins |
| Voltage Supply | 3.3V |
| Max. Ratings |
Storage Temp.: -30 ~ +80 (°C) Operating Temp.: -20 ~ +70 (°C) |
| Package |
TIANAM Original Package; 36 pcs/ctn; weight : TBD; size : 530(L)mm x 350(W)mm x 288(H) |
